BFO-9000 PCB Kit - Customizable Full-Size Split Ortholinear

Need even more keys than the Viterbi? Awesome, we've got a split board with up to 6 rows and 9 columns! Don't need that many rows or columns? Well that's cool too, the PCB features break off pieces to allow for 4 to 6 rows and 7 to 9 columns.

The Rev. 1.1 PCBs are able to be used with MX-compatible, Alps-compatible, and Kailh Low-Profile Choc switches.

Discontinuation Note: The BFO-9000 has been discontinued now, the the PCB design files have been made available on GitHub.

Item Notes

The PCB Kit includes the following:

• 2 BFO-9000 PCBs
• 2 Push buttons for reset
• 2 TRRS jacks
• 108 1N4148 diodes

Case plates are available separately here: Plate Kit

The Name

The name is derived from that big gun in Doom. The 'B' stands for Big, the 'O' for Ortho, and the 'F' for ... well you know.

Case

Here's the case files for a sandwich-style case are still under development, but one can be generated easily via a combination of KLE and SwillKB Builder.

For a 5x7 layout, The BFO-9000 does fit into a Viterbi case.

Build Guide

BFO-9000 Build Guide

Default Keymapping:

The default keymapping that the board is pre-programmed with can be found here: Default Keymaps
